DJI Matrice 4 Series
The DJI Matrice 4 Series is a compact enterprise drone lineup built for teams that need reliable aerial data, fast deployment, and mission-specific sensor options. With models designed for mapping, inspection, thermal operations, low-light response, and automated Dock 3 workflows, the Matrice 4 Series gives organizations a flexible platform that can be matched to their operational needs. Whether your team is looking for a manually deployed drone for field operations or a dock-ready system for remote and automated missions, the Matrice 4 Series offers options for both. Altohelix can help you compare the Matrice 4E, Matrice 4T, Matrice 4D, and Matrice 4TD to choose the right aircraft, software, training, and support path for your program.
Request More InfoCompare DJI Matrice 4 Series Models
DJI Matrice 4T / 4TD
Wide-Angle Camera
1/1.3" CMOS, 48MP Effective Pixels, f/1.7, Format Equivalent: 24mm
Medium Tele Camera
1/1.3" CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 70mm
Tele Camera
1/1.5" CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 168mm
Laser Range Finder
Measurement Range: 1800m
Infrared Thermal Camera
Resolution 640 × 512, f/1.0, Equivalent Focal Length: 53 mm, Uncooled VOx Microbolometer, Supports High-Res Mode (1280x1024)
NIR Auxiliary Light
lFOV: 6°, Illumination Distance: 100m
DJI Matrice 4E / 4D
Wide-Angle Camera
4/3 CMOS, 20MP Effective Pixels, f/2.8-f/11, Format Equivalent: 24mm, Mechanical Shutter(0.5s)
Medium Tele Camera
1/1.3" CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 70mm
Tele Camera
1/1.5" CMOS, 48MP Effective Pixels, f/2.8, Format Equivalent: 168mm
Laser Range Finder
Measurement Range: 1800 m
Laser Range Finder, Precise Measurement
The laser range finder enables real-time precise measurement. Through simple operations such as pin point, line drawing, and area calculation, it can complete tasks like marking target locations for inspection purposes or calculating the area of a wildfire. Additionally, users can share info via the DJI Pilot QR code or FlightHub 2 with relevant personnel to enhance collaboration and workflow efficiency.
Observation Range Recording
DJI Pilot 2 can highlight the center position of the camera frame and ground area observed. It can display the surveyed area on the map, making it especially useful for patrols, and rescue operations in mountainous terrain without clear landmarks.
Efficient Flight, Intelligent Operations
Activate cruise control mode to pilot the drone in a specific direction without constantly pressing the control sticks, making long-distance flights easier. Durring emergencies or disasters, the drone can automatically adjust its flight path and speed based on the surrounding environment, allowing it to reach a designated location without manual adjustmen
Observation Range Recording Super Resolution Telephoto
The tele camera of the Matrice 4 series has significantly improved clarity, featuring 48 MP resolution, capable of capturing incredibly details from signs up to 250 meters away. Additionally, the Matrice 4T/4TD is equipped with an IR-Cut Filter, ensuring 24/7 operations.
Rapid 0.5-Second Interval Shooting
The Matrice 4E/4D wide-angle camera supports rapid 0.5-second interval shooting in both orthophoto and oblique photography modes, enabling high-speed aerial surveying from multiple angles. Additionally, the mapping flight speed can reach up to 21 meters per second, significantly enhancing work efficiency.
Looking For Remote or Automated Drone Deployment?
The Matrice 4D and Matrice 4TD are designed for DJI Dock 3 workflows, giving organizations a path toward remote launch, automated missions, scheduled inspections, and Drone as First Responder-style operations. If your team needs a drone that can be deployed from a fixed location without always being manually launched in the field, Dock 3 is the next step to explore.
